| Model |
d1 (mm) |
d2 |
d3 |
d5 |
d7 |
l1 |
l2 |
l4 |
| FB-12S |
12.00 |
28.57 |
32.00 |
18.50 |
25/26 |
18.20 |
10.2 |
8.00 |
| FB-12M |
12.00 |
30.00 |
35.00 |
18.50 |
25/26 |
18.20 |
10.2 |
8.00 |
| FB-12L |
12.00 |
33.30 |
38.00 |
18.50 |
25/26 |
18.20 |
11.5 |
6.70 |
| FB-13 |
13.00 |
30.00 |
35.00 |
18.50 |
25.00 |
18.00 |
10 |
8.00 |
| FB-15 |
15.00 |
36.50 |
41.50 |
22.50 |
30.50 |
20.50 |
12 |
8.50 |
| FB-16 |
16.00 |
36.50 |
41.50 |
22.50 |
30.50 |
20.50 |
12 |
8.50 |
| FB-16B |
16.00 |
36.50 |
41.50 |
22.50 |
28.00 |
20.00 |
12 |
8.50 |
| FB-16T |
16.00 |
36.50 |
41.50 |
19.30 |
31.50 |
20.50 |
11.5 |
9.00 |
| FB-16L |
16.00 |
38.10 |
43.50 |
22.50 |
30.50 |
20.50 |
11.7 |
8.80 |
| FB-16LD |
16.00 |
38.10 |
43.50 |
22.50 |
28.50 |
20.50 |
11.7 |
8.80 |
| FB-20 |
20.00 |
38/40 |
43.80 |
26.50 |
37.00 |
22.00 |
12.5 |
9.50 |
| FB-20T |
20.00 |
40.00 |
43.80 |
28.00 |
37.00 |
22.00 |
12.5 |
9.50 |
|
| Model |
d1 (mm) |
d2 |
d3 |
d5 |
d7 |
l1 |
l2 |
l4 |
| FB-1/2"S |
12.70 |
28.57 |
32.00 |
18.50 |
25.00 |
17.50 |
9.5 |
8.00 |
| FB-1/2"M |
12.70 |
30.00 |
35.00 |
18.50 |
25.00 |
17.50 |
9.5 |
8.00 |
| FB-5/8" |
15.88 |
36.50 |
41.50 |
22.50 |
30.50 |
20.50 |
12 |
8.50 |
| FB-3/4" |
19.00 |
40.00 |
43.80 |
26.50 |
37.00 |
22.00 |
12.5 |
9.50 |
| FB-5/8"A |
15.88 |
36.50 |
41.50 |
22.00 |
29.00 |
20.00 |
11.5 |
8.50 |
| FB-5/8"B |
15.88 |
36.50 |
41.80 |
22.00 |
28.00 |
21.00 |
12.5 |
8.50 |
| FB-5/8"D |
15.88 |
36.50 |
41.00 |
20.80 |
32.00 |
20.00 |
11 |
9.00 |
| FB-3/4"B |
19.05 |
40.00 |
43.80 |
23.00 |
35.80 |
22.00 |
12.8 |
9.20 |
| FB-3/4"C |
19.05 |
40.00 |
43.80 |
23.00 |
34.00 |
22.00 |
12.8 |
9.20 |
| FB-3/4"D |
19.05 |
40.00 |
44.00 |
22.00 |
36.50 |
19.50 |
10.9 |
8.60 |
| FB-3/4"F |
19.05 |
40.00 |
43.80 |
24.20 |
36.00 |
20.00 |
11.1 |
8.90 |
| FB-1"A |
25.40 |
50.80 |
55.60 |
30.20 |
42.30 |
28.00 |
15.2 |
12.80 |
